www.NabcoEntrances.com OpusControlWiringandProgrammingInstallaonManual
Rev. 3-9-18 P/N C-00139
SECTION 12.6: Standard Wiring for Single Full Automac
Off
Hold Open
On
Off
DN 1519
5
2
3
4
1
BLACK
RED
2
3
4
6
7
12
8910 11
13 14
8
WHITE
Rocker Switch
P.N. A-00805
1
5
6
Door Mounted
Approach Side Sensor
Door Mounted
Swing Side Sensor
BLUE
8
12 1411
13
9
10
15
7
2
34
6
Ac va on
Sensor
Overhead
Swing Side Sensor
(if used)
!!!WARNING!!!
TOTAL POWER CONSUMPTION OF ALL SENSORS
MUST NOT EXCEED 750 MA
N.O.
COM
PWR–
PWR+
N.O.
COM
PWR–
PWR+
N.O. COM
PWR–
PWR+
N.O.COM
PWR–
PWR+
NOTE:
When using door mounted approach side Sensor
Terminal 4 (INPUT 62) must be set to"LE Approach Sensor"
