Nabco Opus Control User Manual

14 of 35
Opus Control Wiring and Programming Installaon Manual www.NabcoEntrances.com
P/N C-00139 Rev 3-9-18
SECTION 9.4: Output Sengs
Output Setting
Parameter Terminal Default Range Description
Output 1 Terminal 7 Full Open
 
Output 2 Terminal 13 Full Close
 
Relay Output 3 Electric
Lock
Terminals
— —
 
 
 
 
Electric Strike Lock 
Electric Magnetic Lock 
Air lock 
Breakout Pass through 
Door Sequencing 
Sensor Monitoring (N.O.) 
 
 
 
 

 
Open Delay Timer N/A 0.4
0.1, 0.4, 1.5 sec




Sequence
Delay Timer
N/A 0
0-10, 12, 15, 20, 25


seconds
Lock Condition N/A Every Fully
Closed


Determines when the electric lock engages
