SECTION 12.3: Safety
DN 1331
1 12VDC +12VDC 2 GND Common for 12V and Signals 361Interior Ac va on
462Exterior Ac va on/Programmable Input
56BSwing Door Con nuous Safety (door mounted, swing side Safety Sensor)
Slide Door Holding Beam
6SWL Swing Door Safety with Lockout (overhead, swing side safety sensor)
Slide Door Sidelite Sensor
7 Out1 Programmable Output
NOTE: • For Safety Sensors equipped with a monitoring func on,
TERMINAL 7 should be connected to "MONITOR" Input located on
the Sensor.
• TERMINAL 7 (Output 1) must be set to "MONITORING". Please see
Programming instruc ons for details.
6
1
2 4 5 1 6
2
3
4
7
5
N.O.COMPWR–PWR+
N.O. COM PWR– PWR+
N.O.
COM
PWR– PWR+
N.O.
COM
PWR– PWR+
MONITOR
6
1
2 6 1 7
2
3
4
7
5
Door Mounted
Approach Side Sensor
Door Mounted
Swing Side Sensor
8
12
14
11
13
9
10
15
7
2
34
6
Overhead Swingside Sensor
