Nabco Opus Control User Manual

21 of 35
www.NabcoEntrances.com OpusControlWiringandProgrammingInstallaonManual
Rev. 3-9-18 P/N C-00139
SECTION 12.2: Acvaon using ON/OFF/Hold-Open Switch
Off
Hold Open
On
Off
Off
Hold Open
On
Off
DN 1330
1 12VDC +12VDC
2 GND Common for 12V and Signals
361Interior Ac va on
462Exterior Ac va on/Programmable Input
56BSwing Door Con nuous Safety (door mounted, swing side Safety Sensor)
Slide Door Holding Beam
6SWL Swing Door Safety with Lockout (overhead, swing side safety sensor)
Slide Door Sidelite Sensor
7 Out1 Programmable Output
5
2
8
12
14
11
13
9
10
1 2 3 45 67
3
4
1
5 671 2 3 4
2
3
4
1
N.O.
COM
N.O.
COM
Exterior Push-Plate
Interior Push-Plate
ALL DEVICES MUST BE
N.O. DRY CONTACT
8
12
14
11
13
9
10
1 2 3 45 67
N.O.COM
Interior Ac va on Exterior Ac va on
PWR–PWR+
N.O.COMPWR–PWR+
ALL DEVICES MUST BE
N.O. DRY CONTACT
POWERED ACTIVATION DEVICES
SENSOR, CARD READER, RADIO RECEIVER, ETC.
!!!WARNING!!!
TOTAL POWER OF ALL SENSORS AND POWERED
ACTIVATION DEVICES MUST NOT EXCEED 750 MA
Non-Powered Ac va on Devices
Powered Ac va on Devices
Radio
Receiver
BLACK
RED BLUE
23467128910 11 13 14
8
BLACK
RED
WHITE
BLUE
128910 11 13 14
8
WHITE
Rocker Switch
P.N. A-00805
Rocker Switch
P.N. A-00805
NOTE:
If not using the Rocker Switch, change
"INPUT BA CIRCUIT" to "NORMALLY OPEN"
