GEM-P1632 Programming Instructions
NAPCO Security Systems
WI897B 8/98
Page 20
Direct Address Programming Example
Example:
Program Zones 6, 7 and 8 as Exit/Entry Follower Zones.
DETERMINE THE DATA ENTRIES
1. Referring to ZONE FEATURES in the Programming Worksheets that follow, Exit/Entry Follower for Zones 5
through 8 are located at address 0506, left digit. Circle
the data values for Zones 5–8.
2. Add the data values for Zones 6, 7 and 8: 2+4+8=14. From Tables 1 and 2, “14” (E) is entered as press
. The right digit (for Zones 1 through 4, none of which are Exit/Entry Follower Zones) is entered as a
blank (•).
PROGRAM THE DATA ENTRIES
1. Enter the panel's Dealer Code (Default = 456789), then press the
button.
2. Answer NO (
) to all questions until “
” is displayed; then press YES (
).
NOTE:
If you pass “
”, scroll backward using the the
button.
3. Press the
button to enter the Address Program Mode. Address "
" will display.
4. Press
to access Address 0506.
The data for both di
its will display and the cursor
will advance to the data field.
5. Press
to enter an “E” in the left digit and press
to enter a blank (•) in the right digit.
6. Press to save.
Address 0506 is now programmed with “E•”.
ZONE OPTION
EXIT/ENTRY FOLLOWER
ZONES
LEFT DATA VALUES
SUM = 14 (CIRCLE
)
ZN08 ZN07 ZN06 ZN05
1
ADDRESS
0506
L ADDR R
E 0506 blank (•)
ZONES
RIGHT DATA VALUES
SUM = 0 (CIRCLE
)
ZN04 ZN03 ZN02 ZN01
842
1
ENTER DATA
DIRECT ADDRESS PROGRAM MODE
