NAPCO Security Systems
GEM-P1632 Programming Instructions
WI897B 8/98
Page 7
Entry/Exit Zones in Area 1
(Appears for New Panel Only)
Directly enter the zone number of any zones which are to be used as
Entry/Exit zones. Valid entries are from 01 to 32. Directly enter each zone
number, including leading zeros. Use number buttons
through
.
NOTE:
Press the
button for a zero. Press to save and then repeat
for any additional zone(s). Press NEXT (
) button to proceed.
NOTE:
Chime will automatically be programmed for all E/E zones. If you are programming a 2 Area system, enter the
total number of zones required for Areas 1 & 2. The Direct Address Program Mode can then be used to remove zone from
Area 1 and place them in Area 2. See Zone Options.
Interior Zones in Area 1
(Appears for New Panel Only)
Directly enter the zone number of any zones which are to be used as Interior
Zones. Valid entries are from 01 to 32. Directly enter each zone number,
including leading zeros. Use number buttons
through
.
NOTE:
Press the
button for a zero. Press to save and then repeat for any
additional zone(s). Press NEXT (
) button to proceed.
NOTE:
All Interior zones will also be automatically programmed as “Exit/Entry Follower” zones. If you are programming a
2 Area system, enter the total number of zones required for Areas 1 & 2. The Direct Address Program Mode can then be
used to remove zones from Area 1 and place them in Area 2. See Zone Options.
Number of Keypads in Area 1
Directly enter the total number of Keypads to be installed in Area 1. Valid
entries are from 01 to 07. Directly enter the number of keypads, including
leading zeros. Use number buttons
through
.
NOTE:
Press the
button for a zero. Press to save . Press NEXT (
) button to
proceed.
NOTE:
Area 2 keypads can only be assigned in Direct Address
Programming. See Keypad Options.
Central Station Receiver 1 Telephone Number
Using number buttons, enter telephone number of up to 16 digits including-
prefix letters, if necessary, for receiver 1. Use number buttons
through
for digits 1–9; press the
button for a zero and
through
for letters B–F, respectively.
NOTE:
Pre-Dial Delay = “D”; Dial-Tone Detection = “E”. Pressing the
button will produce a blank space (•). Press to
save . Press NEXT (
) button to proceed.
NOTE:
Central Station Receiver 2 and 3 Telephone Numbers can only be entered in Direct Address Programming. See
CS Receiver Options.
Central Station Receiver 1 Account Number
Enter an account number of up to four digits. Use number buttons
through
for digits 1–9.
NOTE:
Press the
button for a zero and
press
button for a blank space (•). Press to save . Press
NEXT (
) button to proceed.
NOTE:
Central Station Receiver 2 and 3 Account Numbers can only be entered in Direct Address Programming. See CS
Reporting Options.
(Direct Entry)
(Direct Entry)
(Direct Entry)
(Direct Entry)
(Direct Entry)
EASY MENU DRIVEN PROGRAM MODE
To Next Page
