GEM-P1632 Programming Instructions
WI897B 8/98

Page 27
#%"
CS Telco 1
Subscriber
Opening/Closing ID
Number (Area 1)
ADDRESS 0259-0262
(RIGHT DIGITS 1-4)
0259 0260 0261 0262
RRRR
CS Telco 1
Subscriber
Opening/Closing ID
Number (Area 2)
ADDRESS 0263-0266
(RIGHT DIGITS 1-4)
0263 0264 0265 0266
RRRR
CS Telco 1
Subscriber Event ID
Number (Area 1)
ADDRESS 0267-0270
(RIGHT DIGITS 1-4)
0267 0268 0269 0270
RRRR
CS Telco 2
Subscriber
Opening/Closing ID
Number (Area 1)
ADDRESS 0279-0282
(RIGHT DIGITS 1-4)
0279 0280 0281 0282
RRRR
CS Telco 2
Subscriber Event ID
Number (Area 1)
ADDRESS 0287-0290
(RIGHT DIGITS 1-4)
0287 0288 0289 0290
RRRR
CS Telco 3
Subscriber
Opening/Closing ID
Number (Area 1)
ADDRESS 0299-0302
(RIGHT DIGITS 1-4)
0299 0300 0301 0302
RRRR
CS Telco 3
Subscriber Event ID
Number (Area 1)
ADDRESS 0307-0310
(RIGHT DIGITS 1-4)
0307 0308 0309 0310
RRRR
CS Telco 1
Subscriber Event ID
Number (Area 2)
ADDRESS 0271-0274
(RIGHT DIGITS 1-4)
0271 0272 0273 0274
RRRR
CS Telco 2
Subscriber
Opening/Closing ID
Number (Area 2)
ADDRESS 0283-0286
(RIGHT DIGITS 1-4)
0283 0284 0285 0286
RRRR
CS Telco 2
Subscriber Event ID
Number (Area 2)
ADDRESS 0291-0294
(RIGHT DIGITS 1-4)
0291 0292 0293 0294
RRRR
CS Telco 3
Subscriber
Opening/Closing ID
Number (Area 2)
ADDRESS 0303-0306
(RIGHT DIGITS 1-4)
0303 0304 0305 0306
RRRR
CS Telco 3
Subscriber Event ID
Number (Area 2)
ADDRESS 0311-0314
(RIGHT DIGITS 1-4)
0311 0312 0313 0314
RRRR
CS Telco 1
Subscriber Event ID
Number(System)
ADDRESS 0275-0278
(RIGHT DIGITS 1-4)
0275 0276 0277 0278
RRRR
CS Telco 2
Subscriber Event ID
Number (System)
ADDRESS 0295-0298
(RIGHT DIGITS 1-4)
0295 0296 0297 0298
RRRR
CS Telco 3
Subscriber Event ID
Number (System)
ADDRESS 0315-0318
(RIGHT DIGITS 1-4)
0315 0316 0317 0318
RRRR
Default for CS Telco 1 Subscriber Event ID Number (Area 1) depends on Easy Menu Question “ACCOUNT #”. [Default = blank (•) blank (•) blank (•)
blank (•)] for all other ID Numbers.
CS TELCO SUBSCRIBER ID NUMBERS:
Enter the Subscriber Opening/Closing and Event ID Numbers for any of the 3 CS
Receivers.

1. Enter in corresponding right digit address location (left digit is not used).

2. Enter 3 or 4 digits (depending on the CS receiver format) for each subscriber number from left to right.
NOTE:
Leave trailing
boxes blank (•).

3. Valid entries are: 1-9, 0 and B-F.
NOTE:
A is not permitted.
[Default = blank (•) blank (•) from
address 0319-0330]
ADDRESS
0333-0347
LEFT ADDR RIGHT
0333
0334
0335
0336
0337
0338
0339
0340
0341
0342
0343
0344
0345
0346
0347
CS SYSTEM
REPORTING CODES
Telco Fail
RF Rec. Trouble
Memory Fail
Low Battery
Panel AC Fail
EZM Tamper
Alarm Output Superv.
Ambush
Panic
Fire
Auxiliary
Tamper
Fail to Close
Test Timer
Keyfob Low Battery
ADDRESS
0319-0330
LEFT ADDR RIGHT
blank (•) 0319
blank (•) 0320
blank (•) 0321
blank (•) 0322
blank (•) 0323
blank (•) 0324
blank (•) 0325 blank (•)
blank (•) 0326
blank (•) 0327
0328
0329
0330
CS SYSTEM
REPORTING CODES
Alarm Restore
Trouble
Trouble Restore
Xmitter Low Battery
Xmitter Supervision
Xmitter Tamper
RESERVED
Opening
Closing
Opening after Alarm
Conditional Close
Fail to Open
CS SYSTEM REPORTING CODES:

1. Enter in corresponding address
location (left and right digits).
NOTE:
Left digit is the first digit and right digit
is the second digit in a two digit CS
receiver format.

2. Valid entries are: 1-9, 0 and B-F.
NOTE:
A is not permitted.

3. To disable a code leave boxes
blank (•).
NOTE:
Dark shaded data value box shows
option not available.
PROGRAMMING OPTIONS & WORKSHEETS
