NAPCO Security Systems
GEM-P1632 Programming Instructions
WI897B 8/98
Page 31
%
[Default = blank (•) 1]
ADDRESS 0726
LEFT RIGHT
blank (•)
Keypad 4 Area
Assignment
[Default = blank (•) 1]
ADDRESS 0723
LEFT RIGHT
blank (•)
Keypad 1 Area
Assignment
[Default = blank (•) 1]
ADDRESS 0724
LEFT RIGHT
blank (•)
Keypad 2 Area
Assignment
[Default = blank (•) 1]
ADDRESS 0725
LEFT RIGHT
blank (•)
Keypad 3 Area
Assignment
[Default = blank (•) 1]
ADDRESS 0727
LEFT RIGHT
blank (•)
Keypad 5 Area
Assignment
[Default = blank (•) 1]
ADDRESS 0728
LEFT RIGHT
blank (•)
Keypad 6 Area
Assignment
[Default = blank (•) 1]
ADDRESS 0729
LEFT RIGHT
blank (•)
Keypad 7 Area
Assignment
KEYPAD AREA ASSIGNMENT:
Up to 7 keypads may be programmed, if they are connected.
NOTE:
Keypad Number is configured by setting its jumper settings. By default from the factory, each
keypad is configured as number 1.
1. Select area assignment for each keypad from the table shown.
2. Enter in corresponding right digit address locations above (left digit is not used).
NOTE:
Dark shaded data value box shows option not available.
DATA ENTRIES
LEFT RIGHT
blank (•) 1
blank (•) 2
OPTION
Area 1
Area 2
KEYPAD AREA ASSIGNMENT
KEYPAD OPTIONS:
Select options for any of the 7 keypads.
1. Select the desired option by circling
the data values for each digit (left and right).
2. Add the data values (ex: 15=1+2+4+8) from the selected options.
3. Enter in address location (left and right digits).
NOTE:
Dark shaded data value box shows option not available.
PROGRAMMING OPTIONS & WORKSHEETS
OUTPUT TURNS OFF UPON DISARM:
Select options for any of the 4 Outputs.
1. Select the desired option by circling
the data values for right digit only (left is not used).
2. Add the data values (ex: 15=1+2+4+8) from the selected options.
3. Enter in right digit address location.
NOTE:
Dark shaded data value box shows option not available.
[Default = blank (•) blank (•)]
RIGHT DATA
VALUES
(CIRCLE
)
1
2
4
8
Disarming Area 1
Area 1 PGM1 Output Silenced
Area 2 PGM1 Output Silenced
RESERVED
RESERVED
LEFT DATA
VALUES
(CIRCLE
)
1
2
4
8
Disarming Area 2
Area 1 PGM1 Output Silenced
Area 2 PGM1 Output Silenced
RESERVED
RESERVED
PGM1 Output Turns Off
upon Disarm
ADDRESS 0747
LEFT DIGIT (SUM
OF DATA VALUES)
RIGHT DIGIT (SUM
OF DATA VALUES)
[Default = blank (•) blank (•)]
RIGHT DATA
VALUES
(CIRCLE
)
1
2
4
8
Disarming Area 1
Area 1 PGM2 Output Silenced
Area 2 PGM2 Output Silenced
RESERVED
RESERVED
LEFT DATA
VALUES
(CIRCLE
)
1
2
4
8
Disarming Area 2
Area 1 PGM2 Output Silenced
Area 2 PGM2 Output Silenced
RESERVED
RESERVED
PGM2 Output Turns Off
upon Disarm
ADDRESS 0749
LEFT DIGIT (SUM
OF DATA VALUES)
RIGHT DIGIT (SUM
OF DATA VALUES)
[Default = blank (•) blank (•) from address 0730-0736]
KEYPAD
NO.
1
2
3
4
5
6
7
KEYPAD OPTIONS
LEFT DATA VALUES (CIRCLE
)
RSRVD
PANEL
ACCESS
EASY
ARMING
AMBUSH
8
421
8
421
8
421
8
421
8
421
8
421
8
421
ADDRESS
0730-0736
LEFT ADDR RIGHT
0730
0731
0732
0733
0734
0735
0736
KEYPAD OPTIONS
RIGHT DATA VALUES (CIRCLE
)
RSRVD
KEYPAD
PANIC
KEYPAD
AUXILIARY
KEYPAD
FIRE
8
421
8
421
8
421
8
421
8
421
8
421
8
421
"
