GEM-P1632 Programming Instructions
WI897B 8/98
Page 23
[Default = blank (•) blank (•)]
[Default = 1 blank (•)]
[Default = 1 blank (•)]
[Default = blank (•) blank (•) ]
ADDRESS 0710
LEFT RIGHT
PGM2
Output
Timeout
(min.)
ADDRESS 0712
LEFT RIGHT
Alarm
Output
Timeout
(min.)
DATA ENTRIES
LEFT RIGHT
blank (•) blank (•)
blank (•) 1
blank (•) 2
blank (•) 3
blank (•) 4
blank (•) 5
blank (•) 6
1 blank (•)
FF
DELAY/
TIMEOUT
0 min.
1 min.
2 min.
3 min.
4 min.
5 min.
6 min.
16 min.
255 min.
ADDRESS 0714
LEFT RIGHT
PGM1
Output
Timeout
(min.)
ADDRESS 0713
LEFT RIGHT
Pulse Alarm
Output
Timeout
(min.)
1. Select delay/timeout (0-255 min.) from the table shown.
2. Enter in corresponding address locations above (left and right digits).
3. For a desired delay/timeout not listed do the following:
A. Choose a desired delay/timeout, ex: 20 min.
B. Divide it by 16
OUTPUT TIMEOUTS:
If a timeout of “0 min.” is selected, then
the output will remain active (ON) until the system is reset or disarmed. For UL Residential
Installations, the minimum timeout is 4 minutes. For UL Commercial Installations, the minimum
1 Quotient Left Digit
16 20
16
4 Remainder Right Digit
!"
NUMBER OF RINGS BEFORE PICKUP:
Enter the number of rings before automatic pickup by the
control panel when downloading form a computer (see Glossary at the back for more information).
1. Enter in right digit only (left digit is not used).
2. Valid entries are: 1-9, 0 = 10, B = 11, C = 12, D = 13, E = 14, F = 15
NOTE:
Default is 15 Rings. Dark shaded data shows option not available.
PROGRAMMING OPTIONS & WORKSHEETS
CALLBACK TELEPHONE NUMBER:
Enter telephone number to be used when downloading from a computer (see Glossary at the
back for more information).
1. Enter in right digit only (left digit is not used).
2. Enter up to 20 digits from left to right.
NOTE:
Leave trailing boxes blank (•).
3. Valid entries are: 1-9, B =
button, C =
button, D = 3 sec. pause, E = Wait for dial tone, F = ignore location
[Default = blank (•) for all digits 1-20]
ADDRESS 0236-0255 (RIGHT DIGITS 1-20)
0236 0237 0238 0239 0240 0241 0242 0243 0244 0245 0246 0247 0248 0249 0250 0251 0252 0253 0254 0255
RRRRRRRRRRRRRRRRRRRR
Callback
Telephone
Number
(Digits 1-20)
#$
LEADING DIGITS FOR PAGER FORMAT:
In Pager Format reporting, the message typically begins with “00”..
However, for some pager services, this will cause the Pager's Voice Mail feature to activate. This option allows
you to program these digits to any number desired. Typical Pager report is “003 022 1234”, where 3 is the Event,
22 is the zone, and 1234 is the Subscriber ID number. For example, if the Leading Digits are programmed as “98”,
the Pager report will now appear as “983 022 1234”.
NOTE:
See CS Receiver Options to select Pager Format.
1. Enter in 1st and 2nd Leading Digits in right digit only (left digit is not used) as shown.
2. Valid entries are: 0-9.
Leading Digits for
Pager Format
(1st Digit)
ADDRESS 0256
LEFT RIGHT
blank (•)
[Default = blank (•) blank (•) for both]
Leading Digits for
Pager Format
(2nd Digit)
ADDRESS 0257
LEFT RIGHT
blank (•)
ADDRESS 1183
LEFT RIGHT
blank (•)
No. Rings
Before
Pickup
[Default = blank (•) blank (•)]
