GEM-P1632 Programming Instructions
NAPCO Security Systems
WI897B 8/98
Page 28
Default for Group Zone Report Codes depends on Easy Menu Question “RCVR.
[Default = blank (•) blank (•)]
[Default = blank (•) blank (•)]
[Default = blank (•) blank (•)]
'#!"!%
ADDRESS 0358-0365
CONTROL PANEL ZONES REPORT CODE
ZONE 1 ZONE 2 ZONE 3 ZONE 4 ZONE 5 ZONE 6 ZONE 7 ZONE 8
0358 0359 0360 0361 0362 0363 0364 0365
LRLRLRLRLRLRLRLR
ADDRESS 0366-0369
ZONES REPORT CODE
ZONE 9 ZONE 10 ZONE 11 ZONE 12
0366 0367 0368 0369
LRLRLRLR
ADDRESS 0370-0373
ZONES REPORT CODE
ZONE 13 ZONE 14 ZONE 15 ZONE 16
0370 0371 0372 0373
LRLRLRLR
ADDRESS 0382-0385
ZONES REPORT CODE
ZONE 25 ZONE 26 ZONE 27 ZONE 28
0382 0383 0384 0385
LRLRLRLR
ADDRESS 0386-0389
ZONES REPORT CODE
ZONE 29 ZONE 30 ZONE 31 ZONE 32
0386 0387 0388 0389
LRLRLRLR
ADDRESS 0374-0377
ZONES REPORT CODE
ZONE 17 ZONE 18 ZONE 19 ZONE 20
0374 0375 0376 0377
LRLRLRLR
ADDRESS 0378-0381
ZONES REPORT CODE
ZONE 21 ZONE 22 ZONE 23 ZONE 24
0378 0379 0380 0381
LRLRLRLR
#%"%
7 Gas Alarm
8 Heat Alarm
0 Auxiliary Alarm
B 24 Hour Auxiliary
DATA
ENTRIES
LEFT
1
2
3
4
MODEM CODE
Fire *
Panic
Burglary
Hold up
ZONE REPORT
CODE OPTIONS
DATA ENTRIES
LEFT RIGHT
NOTE:
If “Zone Doubling” (Address 0721) is
not
enabled, then Zones 1-8 are included in the control panel and
Zones 9-32 are EZM Zones. If “Zone Doubling” is enabled, then Zones 1-16 are included in the control panel and
Zones 17-32 are EZM Zones. See Address 0737-0742 to enable “EZM Zone Groups”.
PULSE EVENT CODE
will be the first digit of the 2 digit reporting code. the second digit will be the
second digit of the reporting zone. For example, for zone 9 (address 0366), if the right digit is “3", then
the reporting code is ”39". For example, for zone 15 (address 0372), if the right digit is “4", then the
reporting code is ”45".
MODEM CODES
determine the zone types reported for the following formats: SIA and ADEMCO Point
ID.
1. Select the desired Modem Code for each zone from the table shown.
DISABLE OPENING REPORTS
ADDRESS 0391
LEFT DIGIT (SUM
OF DATA VALUES)
RIGHT DIGIT
blank (•)
LEFT DATA
VALUES
(CIRCLE
)
1
2
4
8
AREA
AREA 1
AREA 2
RESERVED
RESERVED
DISABLE CLOSING REPORTS
ADDRESS 0392
LEFT DIGIT (SUM
OF DATA VALUES)
RIGHT DIGIT
blank (•)
LEFT DATA
VALUES
(CIRCLE
)
1
2
4
8
AREA
AREA 1
AREA 2
RESERVED
RESERVED
ADDRESS 0394
LEFT DIGIT (SUM
OF DATA VALUES)
RIGHT DIGIT (SUM
OF DATA VALUES)
LEFT DATA
VALUES
(CIRCLE
)
1
2
4
8
CS SYSTEM REPORT OPTIONS
Cancel Next Test Timer on any Report
Disable Wait for Silence
Disable Wait for Handshake
Disable Dial Tone Detect
RIGHT DATA
VALUES
(CIRCLE
)
1
2
4
8
CS SYSTEM REPORT OPTIONS
Backup Report on Telco 2
Touch-tone Dialing Only *
Touch-tone Dialing w/Rotary Backup *
RESERVED
* NOTE:
If neither Touch-tone Dialing nor
Touch-tone w/Rotary Backup is selected, then
system defaults automatically to Rotary Dialing.
Leave blank (•) to select Rotary Dialing.
CS AREA & SYSTEM REPORTING OPTIONS:
1. Select the desired option by circling
the data values for each digit (left and
right).
2. Add the data values (ex: 15=1+2+4+8) from the selected options.
3. Enter in address location (left and right digits).
NOTE:
Dark shaded data value box shows option not available.
PROGRAMMING OPTIONS & WORKSHEETS
To Next Page
