Step 2. Verify the Components
Make sure you have the SCXI system components shown in Figure 1.
Figure 1. SCXI System Components
In addition, you need the following items:
•NI-DAQ 7.x software and documentation
• At least one of the following software packages and documentation:
–LabVIEW
– LabWindows
™
/CVI
™
– Visual C++
– Visual Basic
• SCXI product manuals
• 1/8 in. flathead screwdriver
• Numbers 1 and 2 Phillips screwdrivers
• Wire insulation strippers
• Long nose pliers
1 Terminal Block or TBX Accessories (optional)
2 PXI Module
3 SCXI Modules
4 PXI/SCXI Combination Chassis with Controller
5 SCXI Chassis
6 Chassis Power Cord
7 For SCXI Chassis Only
8 Chassis Adapter Assembly
9DAQ Device
