Native Instruments Traktor Kontrol Z2 User Manual

5.2.5 AUX / MIC Section
The AUX / MIC section on the rear panel.
▪ The AUX input is for connecting a standard line-level source such as an MP3 player or CD
player. Like the MIC input, the AUX input is sent straight to the output summing bus after
passing through the tone EQ stage, which is controlled by the TONE knob on the Z2's top
panel (see also ↑5.4.1, AUX / MIC Controls). (For a more detailed description of connect-
ing equipment via aux inputs, please read the separate Setup Guide as instructed in
↑1.3.1, The Setup Guide.)
▪ The MIC input lets you connect a microphone to the Z2. The signal is sent straight to the
Master outputs and is equally distributed between the left and right channels (for a more
detailed description, please read the separate Setup Guide as instructed in ↑1.3.1, The
Setup Guide).
Both MIC and AUX inputs can be used simultaneously — they are simply mixed together and
sent through the tone EQ stage and then through to the outputs. The signal does not pass
through any of TRAKTOR's FX or through the Z2's channel EQs or Filters.
The MIC input can be muted with the on/off switch (see also ↑5.4.1, AUX / MIC Controls) on
the top panel.
5.2.6
GND (Ground) Screws
The ground screws on the rear panel.
TRAKTOR KONTROL Z2 Hardware Reference
Rear Panel
TRAKTOR KONTROL Z2 - Manual - 36

Native Instruments Traktor Kontrol Z2 Specifications

General

Frequency range	20 - 20000 Hz
Channels quantity	6 channels
Supported sample rates	48 kHz
Digital sound processing	24 bit
AUX in	Yes
XLR out	2
AUX out ports	1
Headphone connectivity	3.5 mm/6.35 mm
Product color	Black
USB connector type	USB Type-A, USB Type-B
AC input voltage	115 - 230 V
Power consumption	750 mA
AC input frequency	50 - 60 Hz
Minimum storage drive space	1024 MB
Mac operating systems supported	Mac OS X 10.12 Sierra, Mac OS X 10.13 High Sierra, Mac OS X 10.14 Mojave, Mac OS X 10.15 Catalina
Windows operating systems supported	Windows 10
