Native Instruments Traktor Kontrol Z2 User Manual

▪ VOLUME knob: Use this to adjust the combined mic and aux volume level.
▪ TONE knob: This is a simple, but effective "one-knob" tone control. Turn towards the right
to emphasize higher frequencies (and attenuate lower ones) and towards the left to em-
phasize lower frequencies (and to attenuate higher ones).
The TONE knob can be a quick-fix to possible feedback problems resulting from using a
microphone on stage.
5.4.2 MACRO FX Sections
The MACRO FX control section on the top panel.
The MACRO FX sections — one on each channel — are designated Macro FX controls for the
Macro FX in the TRAKTOR software (see also ↑4.6, Macro FX for information about Macro FX);
however, you can also control other effects' parameters with the MACRO FX controls, in which
case the FX knob will control the effect's third parameter in Single mode, and the first effect in
the chain in Group mode.
In order for any effect to be audible, the relevant FX Unit needs to be activated for the channel
via its FX Assign button (see ↑5.4.11, FX Assign Buttons (1, 2)).
TRAKTOR KONTROL Z2 Hardware Reference
Top Panel
TRAKTOR KONTROL Z2 - Manual - 41

Native Instruments Traktor Kontrol Z2 Specifications

General

Frequency range	20 - 20000 Hz
Channels quantity	6 channels
Supported sample rates	48 kHz
Digital sound processing	24 bit
AUX in	Yes
XLR out	2
AUX out ports	1
Headphone connectivity	3.5 mm/6.35 mm
Product color	Black
USB connector type	USB Type-A, USB Type-B
AC input voltage	115 - 230 V
Power consumption	750 mA
AC input frequency	50 - 60 Hz
Minimum storage drive space	1024 MB
Mac operating systems supported	Mac OS X 10.12 Sierra, Mac OS X 10.13 High Sierra, Mac OS X 10.14 Mojave, Mac OS X 10.15 Catalina
Windows operating systems supported	Windows 10
