Native Instruments Traktor Kontrol Z2 User Manual

5.4.11 FX Assign Buttons (1, 2)
A Deck's FX assign buttons for FX Units 1 and 2.
The FX Assign buttons route the associated Deck (A or B) to either or both of TRAKTOR's FX.
Pressing SHIFT + the FX buttons assigns the lower Decks (C and D) to their respective FX
Units in TRAKTOR.
Although the Z2 has its own great-sounding filters and EQs, the FX are not internal — they
are not available in standalone mode. Therefore, to use TRAKTOR's FX, you'll need to be in
TRAKTOR control mode.
By default, TRAKTOR's FX routing is "post fader," which means that the effect is not affected
by the channel fader postion. For example, if you have a channel assigned to a reverb effect,
bringing the channel fader down will not change the reverb volume. This is very useful for
"fade to delay" or "fade to reverb" situations. You can always change to Insert mode if you pre-
fer to control the effects level with the channel faders. See the TRAKTOR Manual for further
reference on Insert and Post Fader modes.
5.4.12 7-Segment Displays
One of the 7-segment displays displaying a loop/move size on the Z2.
The 7-segment displays are used for displaying information about loop/move size, and settings
options. For further information, refer to ↑5.4.4, LOOP (SIZE) Encoders and ↑5.4.13, Status/
Mode Indicators.
TRAKTOR KONTROL Z2 Hardware Reference
Top Panel
TRAKTOR KONTROL Z2 - Manual - 54

Native Instruments Traktor Kontrol Z2 Specifications

General

Frequency range	20 - 20000 Hz
Channels quantity	6 channels
Supported sample rates	48 kHz
Digital sound processing	24 bit
AUX in	Yes
XLR out	2
AUX out ports	1
Headphone connectivity	3.5 mm/6.35 mm
Product color	Black
USB connector type	USB Type-A, USB Type-B
AC input voltage	115 - 230 V
Power consumption	750 mA
AC input frequency	50 - 60 Hz
Minimum storage drive space	1024 MB
Mac operating systems supported	Mac OS X 10.12 Sierra, Mac OS X 10.13 High Sierra, Mac OS X 10.14 Mojave, Mac OS X 10.15 Catalina
Windows operating systems supported	Windows 10
