5.3.1 PHONES Section
The PHONES sockets on the front panel.
The Z2 lets you connect two sets of headphones at the same time. The output specs of the
PHONES jacks are identical, only their size differs.
▪ Large headphone jack: For 1/4-inch stereo headphone plugs.
▪ Small headphone jack: For 1/8-inch stereo headphone plugs.
Adjust the levels for both headphone jacks with the HP VOLUME knob on the Z2's top pan-
el.
5.3.2 XF REVERSE Switch
The XF REVERSE switch on the front panel.
You can invert the crossfader. When XF REVERSE is ON, an indicator will illuminate at the
bottom of the level meter display on the top panel, and the crossfader's mixer channel assign-
ments will be swapped.
In TRAKTOR mode this will also work; activating XF REVERSE will then switch the software's
crossfader assignments.
TRAKTOR KONTROL Z2 Hardware Reference
Front Panel
TRAKTOR KONTROL Z2 - Manual - 38

Native Instruments Traktor Kontrol Z2 Specifications

General

Frequency range	20 - 20000 Hz
Channels quantity	6 channels
Supported sample rates	48 kHz
Digital sound processing	24 bit
AUX in	Yes
XLR out	2
AUX out ports	1
Headphone connectivity	3.5 mm/6.35 mm
Product color	Black
USB connector type	USB Type-A, USB Type-B
AC input voltage	115 - 230 V
Power consumption	750 mA
AC input frequency	50 - 60 Hz
Minimum storage drive space	1024 MB
Mac operating systems supported	Mac OS X 10.12 Sierra, Mac OS X 10.13 High Sierra, Mac OS X 10.14 Mojave, Mac OS X 10.15 Catalina
Windows operating systems supported	Windows 10
