Native Instruments Traktor Kontrol Z2 User Manual

5.4.20 Level Meters
The level meters in between the volume faders on the top panel.
The Z2's level meters are located right above the crossfader. In their factory default setting,
they show the left/right master output ("MST" on the Z2) and the mono-summed levels of
Decks A and B.
By changing the mixer settings (see ↑5.4.13, Status/Mode Indicators) you can set the display
to indicate the levels of Decks C and D instead of the master output.
Crossfader Reverse Indicator
The XF REVERSE indicator lights up at the bottom of the levels display when the XF REVERSE
switch is activated (on the front panel of the Z2, see also ↑5.3, Front Panel).
Crossfader Reverse only affects a channel in Direct mode. Refer to the TRAKTOR Manual
for further information on Direct mode.
TRAKTOR KONTROL Z2 Hardware Reference
Top Panel
TRAKTOR KONTROL Z2 - Manual - 62

Native Instruments Traktor Kontrol Z2 Specifications

General

Frequency range	20 - 20000 Hz
Channels quantity	6 channels
Supported sample rates	48 kHz
Digital sound processing	24 bit
AUX in	Yes
XLR out	2
AUX out ports	1
Headphone connectivity	3.5 mm/6.35 mm
Product color	Black
USB connector type	USB Type-A, USB Type-B
AC input voltage	115 - 230 V
Power consumption	750 mA
AC input frequency	50 - 60 Hz
Minimum storage drive space	1024 MB
Mac operating systems supported	Mac OS X 10.12 Sierra, Mac OS X 10.13 High Sierra, Mac OS X 10.14 Mojave, Mac OS X 10.15 Catalina
Windows operating systems supported	Windows 10
