Loop Recorder Controls
Button Function
Button 1 Size (LED is blue)
Button 2 Undo (LED is blue)
Button 3 Record (LED is red)
Button 4 Play (LED is green)
The LEDs are brightly lit when the buttons are active.
6.6 Virtual USB I/O Routing
A word on the routing of the virtual USB channels in the software.
USB Outputs
▪ USB OUT 1/2: This signal is fed directly to the Main bus of the Z2 mixer. This signal goes
straight to the XLR/TRS/RCA outputs (via their VOLUME knobs) and to the headphones
when the CUE MIX knob is set clockwise. The crossfader and individual volume faders
have no affect on this output.
▪ USB OUT 3/4: This signal is fed directly to the headphones and requires that the CUE MIX
knob is counter-clockwise in order to hear.
USB Inputs
▪ USB IN 1/2: This is the mic/aux signal.
▪ USB IN 3/4: This is the Channel A Phono or Line Input (depending on the position of the
PH/LN switch).
▪ USB IN 5/6: This is the Channel B Phono or Line Input (depending on the position of the
PH/LN switch).
▪ USB IN 7/8: This is the output of the entire mixer routed back to the computer for the pur-
pose of recording.
Appendix
Virtual USB I/O Routing
TRAKTOR KONTROL Z2 - Manual - 81

Native Instruments Traktor Kontrol Z2 Specifications

General

Frequency range	20 - 20000 Hz
Channels quantity	6 channels
Supported sample rates	48 kHz
Digital sound processing	24 bit
AUX in	Yes
XLR out	2
AUX out ports	1
Headphone connectivity	3.5 mm/6.35 mm
Product color	Black
USB connector type	USB Type-A, USB Type-B
AC input voltage	115 - 230 V
Power consumption	750 mA
AC input frequency	50 - 60 Hz
Minimum storage drive space	1024 MB
Mac operating systems supported	Mac OS X 10.12 Sierra, Mac OS X 10.13 High Sierra, Mac OS X 10.14 Mojave, Mac OS X 10.15 Catalina
Windows operating systems supported	Windows 10
