natus Quantum - Product Images and Description; Quantum Amplifier System Components

User & Service Manual Natus Quantum Amplifier
31
Li-Polymer Battery Specifications (Inside Quantum Main Breakout) - Internal Rechargeable
Battery Type
Lithium Polymer
Rated Capacity
2260 mAh
Voltage
3.7V
Watt-hour Rating
8.4Wh
Charging Method
Constant Current + Constant Voltage
Maximum Charge Voltage
4.2V (±50mV)
Maximum Continuous Charge Current
1080 mA
Maximum Continuous Discharge Current
2000mA
Operating Conditions
Charging Temperature
0ºC to +45ºC
Discharging Temperature
-20ºC to +60ºC
Humidity
65 ± 20%RH
Approvals
UL 1642
Sample rates and corresponding -3dB (+/-5%) bandwidths supported by the amplifier include:
Fs(Hz)
BW (Hz)
Connection Mode
256
109
USB / LAN
512
219
USB / LAN
1024
439
USB / LAN
2048
878
USB / LAN
4096
1757
LAN
8192
3514
LAN
16384
4288
LAN
