User & Service Manual Natus Quantum Amplifier
85
19. Appendix B
19.1. Bulk Connector Pin Box Input
To connect a pre-wired headset or assembly to the bulk connector pin boxes, a Mini D Ribbon 68-pin
female type latch connector is required. This should come from the manufacturer of the pre-wired
headset or assembly or a 3
rd
party vendor. The following shows the layout of the bulk connector pin box
inputs.
19.2. Bulk Connector Pin Box Input Wiring Diagram
Pair
Cond
1st Conductor
Pin
Channel
Cond
2nd Conductor
Pin
Channel
Solid
Band
Solid
Band
1
1
Black
Red
N/C
N/C
2
Red
Black
3
TP5
2
3
Black
White
66
GND
4
White
Black
7
C1
3
5
Black
Green
9
C2
6
Green
Black
28
C3
4
7
Black
Blue
27
C4
8
Blue
Black
57
C5
5
9
Black
Yellow
24
C6
10
Yellow
Black
22
C7
6
11
Black
Brown
20
C8
12
Brown
Black
21
C9
7
13
Black
Orange
51
C10
14
Orange
Black
48
C11
8
15
Red
White
14
C12
16
White
Red
47
C13
9
17
Red
Green
11
C14
18
Green
Red
41
C15
10
19
Red
Blue
10
C16
20
Blue
Red
42
C17
11
21
Red
Yellow
8
C18
22
Yellow
Red
60
C19
12
23
Red
Brown
61
C20
24
Brown
Red
59
C21
13
25
Red
Orange
56
C22
26
Orange
Red
25
C23
14
27
Green
White
55
C24
28
White
Green
53
C25
15
29
Green
Blue
50
C26
30
Blue
Green
19
C27
