natus Quantum - 10-10;10-20 Pin Box

User & Service Manual Natus Quantum Amplifier
37
6.5.2. 10-10/10-20 Pin Box
1
Standard 10-10/10-20 Channel Inputs. See Connecting the 10-10/10-20 Pin box to the Quantum
Breakout for additional information.
NOTE: The 10-10/10-20 pinbox is unavailable with the Quantum 64 breakout.
6.5.2.1. 10-10/10-20 Pin Box (Side View)
1
Additional Channel Inputs.
