Getting Started with MAXserver Access Servers

0038

122

Examples

This command disables the primary initialization record. With this record

disabled, the access server first attempts to load or dump using information

in the secondary initialization record.

XYPLEX>> DEFINE SERVER LOADDUMP PRIMARY DISABLED

This command enables all initialization records.

XYPLEX>> DEFINE SERVER LOADDUMP ALL ENABLED
