Figure 16 shows an octopus cable with a 50-pin Telco connector:

50-pin Telco connector

(male or female)

Eight male RJ-45

connectors

Figure 16 - Octopus Cable with 50-pin Telco Connector

Figure 17 shows an octopus cable with a 36-pin female Telco DEConnect

connector. Figure 18 shows an octopus cable with a 36-pin male Telco

DEConnect connector.

36-pin female Telco

DEConnect connector

Eight male RJ-45

connectors

Figure 17 - Octopus Cable With 36-pin Female DEConnect Connector
