Getting Started with MAXserver Access Servers
0038
148
1. Insert SIMM at 30° angle. Press down.
2. Press forward, until
SIMM snaps into place.
(Rear of unit)
Figure 39 - Inserting SIMM into Socket
10. Make sure that the SIMMs are secure within the retainers.
11. Replace the MAXserver cover, and secure it with the four screws you had
removed.
