NBase-Xyplex MAXserver 1608A - Figure 19 - Connecting a Maxserver to DB-25 Distribution Panel

164 pages

Save Page as PDF

To Next Page

To Previous Page

Getting Started with MAXserver Access Servers

0038

Octopus cable: 8 RJ-45

to 50-pin female Telco

Octopus cable: 8 DB-25

(male or female) to 50-pin

male Telco

Distribution panel

MAXserver

1620/1640

Figure 19 - Connecting a MAXserver to DB-25 Distribution Panel
