Getting Started with MAXserver Access Servers
0038
13
About the MAXserver
The MAXservers are standalone access servers that provide:
Serial Ports – The MAXserver is available in the following configurations:
·
The MAXserver 1620 provides 20 asynchronous serial communication
ports with RJ-45 interfaces.
·
The MAXserver 1640 provides 40 asynchronous serial communication
ports with RJ-45 interfaces. (See Figure 4 for connector signal
assignments.)
·
The MAXserver 1608 provides 8 asynchronous serial communication
ports with RJ-45 interfaces.
·
The MAXserver 1604 provides 4 asynchronous serial communication
ports with RJ-45 interfaces.
Figure 4 and Figure 5 show rear and front views of the MAXserver 1620 and
MAXserver 1640. Figure 6 and Figure 8 show rear and front views of the
MAXserver 1608A and MAXserver 1604.
NOTE: The front and rear panels of the MAXserver 1608A are
identical to the MAXserver 1620 and 1640 except for the
number of ports available.
Ethernet Interfaces -- A 15-pin standard Ethernet Interface Attachment
Unit Interface (AUI) connector and a 10Base-T Ethernet interface (RJ-45
connector). (See Figure 15 for AUI connector signal assignments.)
TCP/IP and LAT Protocol Support -- The MAXserver provides
concurrent support for the DEC Local Area Transport (LAT®) and TCP/IP
protocols.
