Getting Started with MAXserver Access Servers

0038

privileged mode.

XYPLEX>>

See the Commands Reference Guide for the commands that require the user

to be in Privileged mode. The unit is now ready to accept any of the

commands described in the Commands Reference Guide. You can obtain on-

screen information about the access server commands by typing HELP and

pressing <RETURN>:

XYPLEX>

HELP
