7167 Owner’s Manual Chapter 6: Commands
November 2003
138
Select Print Modes
ASCII: ESC ! n
Hexadecimal: 1B 21 n
Decimal:
27 33 n
Value of n:
Pitch selection (standard, compressed, double high, or
double wide.)
Bit Function 0 1
Bit 0 Pitch
Standard Pitch
1
15.6 CPI (Receipt)
44 Col/Line (80 mm)
32 Col/Line (58 mm)
13.9 CPI (Slip)
45 Col/Line
Compressed Pitch
20.3 CPI (Receipt)
56 Col/Line (80 mm)
42 Col/Line (58 mm)
17.1 CPI (Slip)
55 Col/Line
Bit 3 Emphasized
Mode
Canceled Set
Bit 4 Double-
high
2
Canceled Set
Bit 5 Double-wide Canceled Set
Bit 7 Underlined
Mode
Canceled Set
Bits 1, 2, 6 are not used.
1
Standard and compressed pitch cannot be used together in the same line.
2
Double-high characters cannot be used with normal characters in the same
line, nor can they be used on the slip station.
Default: 0 (for bits 0, 3, 4, 5, 7)
Selects the print mode: standard, compressed, double high, or double wide.
Example:
MSComm1.Output = Chr$(&H1B) & Chr$(&H21) & Chr$(n)
Related Information:
