7167 Owner’s Manual Chapter 6: Commands
November 2003
225
Scanner Function Commands
4
pL, pH specify (pL + (pH x 256)) as the number of bytes after pH (fn and m).
Scanning Threshold FS ( g pL pH fn m d1 d2 d3 (when fn = 40)
The threshold level of the scanning density is specified by this command.
ASCII FS ( g pL pH fn m d1 d2 d3
Hex 1C 28 67 pL pH fn m d1 d2 d3
Decimal 28 40 103 pL pH fn m d1 d2 d3
Para Value (pL + pH x 256) = 5 (pL =5, pH = 0)
fn = 40;m = 48;d1 = 1;d2 = 49;-128 <
d3 < 127;
Default d3 = 0
d3
Hex Decimal Function
80H – FEH -128 - - 1 Specifies a density lighter than the standard density level (the
lightest density: – 128)
00H 0 Specifies the standard density level
01H – 7FH 1 – 127 Specifies a density darker than the standard density level (the
darkest density – 127)
4
These commands are supported only by 7167-1035 and 7167-2035.
