Scanning Area FS ( g pL pH fn x1 y1 x2 y2 (when fn = 41)
The area on the check to be scanned is defined by this function.
ASCII FS ( g pL pH fn x1 y1 x2 y2
Hex 1C 28 67 pL pH fn x1 y1 x2 y2
Decimal 28 40 103 pL pH fn x1 y1 x2 y2
Range (pL + pH x 256) = 5 (pL =5, pH = 0)
fn = 41
0 <
x1 < 101
0 < y1 < 229
x1 < x2 < 102, x2=0
y1 < y2 <
230, y2=0
Default x1 = 0
y1 = 0
x2 = 70
y2 = 0
• x1, y1 Specifies the starting point to scan.
• x2, y2 specifies the end point that is to be scanned.
• The possible scanning range is 102 mm (4.02) in the X direction and 230 mm (9.06) in
the Y direction.
x2 > 102 or x2 = 0 specifies the maximum scanning range (=102) in X direction
y2 > 230 specifies the maximum scanning range (=230) in Y direction
If y2 = 0, the scanning range is to the bottom of the sheet within the maximum scanning range of
230 mm.
• All setting values are specified in millimeters for the distance from the origin (lower left
corner in the check).
Sample check
origin
