NEC LED-FA025i2-220 - Grip Handles; Figure 14: Grip Handle in Open and Closed Positions; Figure 15: Grip Handles in Use

26
3.5.2.3 Grip Handles
The grip handles (Figure 14) are bolted into the cabinet, middle-center, left and right from the hub
board. These provide for easy handling during installation and maintenance in the open-position,
and conveniently collapse into the cabinet when not in use (Figure 14, Figure 15).
Figure 14: Grip Handle in Open and Closed Positions
Figure 15: Grip Handles in Use
Open
Closed
