6 ASSEMBLE COMPONENTS
Notice
Read the safety guidelines, which are included in the delivery. Follow them strictly to ensure
safety and a high-performance LED system!
6.1 Install Mounting bars for Wall Mounting
This section is a guide to the mounting of the Mounting bar and describes the following in more
detail:
 Prepare the support structure according to the installation site requirements.
 Prepare the wall for installation.
 Then fix the structure on its designated place according to the static requirements.
Table 6: Mounting bar – Installation requirements
No. of People
2
Tools
Ladder/ elevated working platform
Tools for mounting (e.g. hammer,
screwdriver, Allen key, jaw spanner)
Drilling equipment (e.g. drilling machine
and fitting attachment/head)
depending on mounting surface,
wall material/condition
Mounting material (screws, dowels etc.)
depending on
 overall weight of chosen screen
system
 mounting surface, wall
material/condition
Measurement tools (e.g. rule, spirit level)
Alignment bar
Included in delivery, flat black bar
Equipment
See for 3.3 Framesets for Bundles specifications related to:
 Frameset for LED-FA012i2-110 and LED-FA019i2-110 (4×4 Modules)
 Frameset for LED-FA015i2-137 (5×5 Modules)
 Frameset for LED-FA019i2-165 (6×6 Modules)
 Frameset for LED-FA012i2-220 and LED-FA025i2-220, LED-FA038i2-220
(8×8 Modules)
Prepare the Wall Surface 6.1.1
 Remove debris and clean the wall surface.
 Measure the dimensions for the bundle according to wall frame specifications for the target
frameset: 4×4, 5×5, 6×6, 8x8.
Notice
 Ensure proper ventilation of the LED Wall. For more information, see 3.6 Ventilation
Requirements.
 Consider the cable plans, see 15.1 Cable Plans and ensure the cables can be placed properly.
