NEC SL1100 - Connection Types; Create SL1100 Dial up Connection

NEC SL1100 Issue 3.01
PC Programming Manual A - 3
___________________________________________________________________________________
___________________________________________________________________________________
To make a connection between PCPro and the system:
1. Select a Connection Type and specify the settings relevant to the
selected type.
2. Specify the User Name and Password used to allow the connection.
3. Alternatively, steps 1~2 can be skipped loading a defined connection
account (refer to Appendix D - Connection Accounts).
4. Press the Connect button.
After a successful connection, the connection settings that are used are
set to the File Properties.
 With SL1100 PC Pro 3.5 or higher, after connecting PC Pro automatically downloads the
database if there has been no changes to the new/default database.
 If one change is made to the default database the download does not happen, even if the
change is set back.
2.2.1 Connection Types
PCPro supports two types of connections to a system.
Connection Types for SL1100:

IP
An IP Connection can be made via a LAN or the Internet. The IP
address specified should match the system setting 10-12-01. If
connecting to the ethernet port on the VoIP daughter board, use the
IP address setting in 10-12-09.
 Dial-up
An IP via Dial-up can be made via a dial-up connection, either
through ISDN or an analog modem.

The Dial-up connection has to be up and connected before trying to
use this connection.
To install dial up connection, refer to paragraph 2.2.2 Create SL1100 Dial
Up Connection on page A-3.
2.2.2 Create SL1100 Dial Up Connection
When connecting an SL1100 via modem, a Dial Up Connection
(PPP) must be created. The following steps describe how to set up
the Dial Up Connection (PPP).
1. Click Start >Settings>Network Connections.
