PC Programming Manual G - 1
___________________________________________________________________________________
Appendix G DIM File Download
SECTION 1OVERVIEW
The DIM File Download feature supports downloading a DIM log file using PCPro. A
DIM log file contains operational, system information, and critical information about
the system.
SECTION 2OPERATION
Use the following procedure to download a DIM log file using PCPro.
1. From the PCPro toolbar, select Tools> DIM File Download. A DIM File
Download dialog box appears, Figure G-1 - DIM File Download.
 The DIM File Download menu is only available when PCPro is connected to the system.
Figure G-1 DIM File Download
