Chapter 4: Drive Connection 129
Table 25 One CDE3994 Controller-Drive Tray and Two Drive Trays with Inverted
ESMs
NOTE If you have drive trays with inverted ESM canisters, see "ESM Canister
Arrangements" on page 69.
Drive Channel
Connection Point Connection Point
Tray or Component
Port Number and
Location
Tray or Component
Port Number and
Location
1 Controller A 1 Drive tray 2 ESM A, port 1B
Controller A 2 Drive tray 1 ESM A, port 1B
2 Controller B 1 Drive tray 1 ESM B, port 1B
Controller B 2 Drive tray 2 ESM B, port 1B
