GS108T and GS110TP Smart Switch Software Administration Manual
4-24 Configuring Quality of Service
v1.0, April 2010
6. To remove a policy from the selected interface(s) select None from the Policy In menu, and
then click Apply.
7. Click Cancel to cancel the configuration on the screen and reset the data on the screen to the
latest value of the switch.
Service Statistics
Use the Service Statistics page to display service-level statistical information about all interfaces
that have DiffServ policies attached.
To display the page, click the QoS DiffServ tab and then click the Advanced Service
Statistics link.
The following table describes the information available on the Service Statistics page.
Figure 4-14
Table 4-2. Service Statistics Fields
Field Description
Interface Displays the interface for which service statistics are to display.
Direction Displays the direction of packets for which service statistics display, which is always
In.
Policy Name Displays the policy associated with the selected interface.
