ACL Wizard
The ACL Wizard simplifies the ACL rule configuration process. The Wizard contains a short list
of access criteria that you can either permit or deny. When you select the permit or deny link
associated with the access criteria, you are redirected to a page that is automatically configured
with several of the settings.
To display the ACL Wizard page, click Security ACL.
To use the ACL Wizard:
1. Determine the type of ACL to configure and create a MAC ACL, standard IP ACL, or
extended IP ACL.
• To permit or deny traffic based on the Source MAC Address, create a MAC ACL.
• To permit or deny traffic based on the Destination MAC Address, create a MAC ACL.
• To permit or deny traffic based on the Source IP Address, create a Standard ACL.
• To permit or deny traffic based on the Destination IP Address, create an Extended ACL.
Note: Before you use the ACL Wizard to configure rules, you must create either a MAC
ACL, Standard IP ACL, or Extended IP ACL that will contain the rules. To create a
MAC ACL, see “MAC ACL” on page 5-44. To create a standard or extended IP
ACL, see “IP ACL” on page 5-50.
Figure 5-25
