Device View
The Device View is a Java
®
applet that displays the ports on the switch. This graphic provides an
alternate way to navigate to configuration and monitoring options. The graphic also provides
information about device ports, current configuration and status, table information, and feature
components.
The Device View is available from the System Device View page.
The port coloring indicates whether a port is currently active. Green indicates that the port is
enabled, red indicates that an error has occurred on the port, or red indicates that the link is
disabled.
Figure 1-11 shows the Device View of the GS108T.
Figure 1-12 shows the Device View of the GS110TP.
Click the port you want to view or configure to see a menu that displays statistics and
configuration options. Click the menu option to access the page that contains the configuration or
monitoring options.
Figure 1-11
Figure 1-12
