GS108T and GS110TP Smart Switch Software Administration Manual
2-32 Configuring System Information
v1.0, April 2010
To configure global LLDP settings:
1. Configure the following LLDP properties.
• TLV Advertised Interval. Specify the interval at which frames are transmitted. The
default is 30 seconds, and the valid range is 1–32768 seconds.
• Hold Multiplier. Specify multiplier on the transmit interval to assign to Time-to-Live
(TTL). The default is 4, and the range is 2–10.
• Reinitializing Delay. Specify the delay before a reinitialization. The default is 2 seconds,
and the range is 1–10 seconds.
• Transmit Delay. Specify the interval for the transmission of notifications. The default is 5
seconds, and the range is 5–3600 seconds.
Note: You can also access the LLDP Configuration page by clicking System LLDP
Advanced LLDP Configuration.
Figure 2-18
