GS108T and GS110TP Smart Switch Software Administration Manual
2-38 Configuring System Information
v1.0, April 2010
The following table describes the LLDP local information that displays for each port.
Click Refresh to refresh the page with the most current data from the switch.
To view additional details about a port, click the name of the port in the Interface column of the
Port Information table.
A popup window displays information for the selected port.
Figure 2-22
Table 2-7. LLDP Local Information Fields
Field Description
Interface Select the interface with the information to display.
Port ID Subtype Identifies the type of data displayed in the Port ID field.
Port ID Identifies the physical address of the port.
Port Description Identifies the user-defined description of the port. To configure the Port
Description, see “Ports” on page 3-1.
Advertisement Displays the advertisement status of the port.
