NETGEAR GS908E User Manual

Use the NETGEAR Switch Discovery Tool to Access the
Switch
For easiest access, we recommend that you cable the switch to a network with a router or DHCP server
that assigns IP addresses, power on the switch, and then use a computer that is connected to the same
network as the switch.
The NETGEAR Switch Discovery Tool lets you discover the switch in your network and access the local
browser interface of the switch from a Mac or a 64-bit Windows-based computer.
To install the NETGEAR Switch Discovery Tool, discover the switch in your network, and
access the local browser interface of the switch:
1. Download the Switch Discovery Tool by visiting netgear.com/support/product/gs908e.aspx#download.
Depending on the computer that you are using, download either the Mac version or the version for a
64-bit Windows-based computer.
2. Temporarily disable the firewall, Internet security, antivirus programs, or all of these on the computer
that you use to configure the switch.
3. Unzip the Switch Discovery Tool files, double-click the Setup.exe file (for example,
NetgearSDT-V1.1.115_Win_x64_Setup.exe), and install the program on your computer.
The installation process places a NETGEAR Switch Discovery Tool icon on your desktop.
4. Reenable the security services on your computer.
5. Power on the switch.
The DHCP server assigns the switch an IP address.
6. Connect your computer to the same network as the switch.
You can use a WiFi or wired connection. The computer and the switch must be on the same Layer 2
network.
7. Open the Switch Discovery Tool.
To open the program, double-click the NETGEAR Switch Discovery Tool icon on your desktop.
The initial page displays a menu and a button.
8. From the Choose a connection menu, select the network connection that allows the Switch Discovery
Tool to access the switch.
9. Click the Start Searching button.
The Switch Discovery Tool displays a list of Smart Managed Plus Switches that it discovers on the
selected network.
For each switch, the tool displays the IP address.
10. To access the local browser interface of the switch, click the ADMIN PAGE button.
The login page of the local browser interface opens.
11. Enter the switch password.
The default password is password. The password is case-sensitive.
The HOME page displays.
Install and Access the Switch in Your Network
19
8-Port Gigabit Ethernet Smart Managed Plus Switch Model GS908E

NETGEAR GS908E Specifications

General

Switch type	Managed
Quality of Service (QoS) support	Yes
Safety	IEC 60950-1:2005(ed.2) + A1:2009 + A2:2013, UL 60950-1, CAN/CSA C22.2 No. 60960-1-07, EN 60950-1: 2006 + A11:2009 + A1:2010 + A12:2011 + A2:2013, IEC 60950-1:2005 (ed.2)+A1:2009+A2:2013, AS/NZS 60950.1:2015
Stackable	-
Certification	47 CFR FCC Part 15, ICES-003:2016, ANSI C63.4:2014, EN 55022:2010 + AC:2011, EN 55024:2010, EN 61000-3-2:2014, EN 6100-3-3:2013, AS/NZS CISPR 22:2009 + A1:2010, VCCI V-3/2015.04, V-4/2012.4
Product color	Black, White
Rack mounting	No
Number of multicast groups filtered	128
USB 2.0 ports quantity	2
Installed SFP modules quantity	0
Basic switching RJ-45 Ethernet ports type	Gigabit Ethernet (10/100/1000)
Basic switching RJ-45 Ethernet ports quantity	8
AC input voltage	100 - 240 V
AC input frequency	50 - 60 Hz
Power consumption (max)	26.3 W
Power consumption (typical)	3.3 W
Number of VLANs	64
Networking standards	IEEE 802.1Q, IEEE 802.1p
Virtual LAN features	Port-based VLAN
DHCP features	DHCP client
Jumbo frames	9000
Forwarding rate	11.9 Mpps
Number of queues	4
MAC address table	4000 entries
Heat dissipation	89.8 BTU/h
Operating altitude	0 - 3000 m
Storage temperature (T-T)	-20 - 70 °C
Operating temperature (T-T)	0 - 40 °C
Storage relative humidity (H-H)	0 - 95 %
Operating relative humidity (H-H)	0 - 90 %
Harmonized System (HS) code	85176990

Weight and Dimensions

Depth	164 mm
Width	234 mm
Height	33 mm
Weight	370 g
