NETGEAR GS908E User Manual

To activate the 802.1Q-based VLAN mode:
1. Open a web browser from a computer that is connected to the same network as the switch or to the
switch directly through an Ethernet cable.
2. Enter the IP address that is assigned to the switch.
The login page displays.
3. Enter the switch password.
The default password is password. The password is case-sensitive.
The HOME page displays.
4. From the menu at the top of the page, select SWITCHING.
The Quality of Service (QoS) page displays.
5. From the menu on the left, select VLAN.
The VLAN page displays.
6. In the 802.1Q-based VLAN (Advanced Mode) section, click the ACTIVATE button.
A pop-up window opens, informing you that the current VLAN settings will be lost.
7. Click the CONTINUE button.
Your settings are saved and the pop-up window closes. By default, VLAN 1 is added.
Create an 802.1Q-Based VLAN
An 802.1Q-based VLAN configuration lets you assign ports on the switch as tagged or untagged members
to a VLAN with an ID number in the range of 1–4094. By default, all ports are untagged members of VLAN 1.
To create an 802.1Q-based VLAN:
1. Open a web browser from a computer that is connected to the same network as the switch or to the
switch directly through an Ethernet cable.
2. Enter the IP address that is assigned to the switch.
The login page displays.
3. Enter the switch password.
The default password is password. The password is case-sensitive.
The HOME page displays.
4. From the menu at the top of the page, select SWITCHING.
The Quality of Service (QoS) page displays.
5. From the menu on the left, select VLAN.
The VLAN page displays.
If you did not yet activate the 802.1Q-based VLAN mode, see Activate the 802.1Q-Based VLAN Mode
on page 40.
6. In the 802.1Q-based VLAN section, click the ADD VLAN button.
Use VLANS for Traffic Segmentation
41
8-Port Gigabit Ethernet Smart Managed Plus Switch Model GS908E

NETGEAR GS908E Specifications

General

Switch type	Managed
Quality of Service (QoS) support	Yes
Safety	IEC 60950-1:2005(ed.2) + A1:2009 + A2:2013, UL 60950-1, CAN/CSA C22.2 No. 60960-1-07, EN 60950-1: 2006 + A11:2009 + A1:2010 + A12:2011 + A2:2013, IEC 60950-1:2005 (ed.2)+A1:2009+A2:2013, AS/NZS 60950.1:2015
Stackable	-
Certification	47 CFR FCC Part 15, ICES-003:2016, ANSI C63.4:2014, EN 55022:2010 + AC:2011, EN 55024:2010, EN 61000-3-2:2014, EN 6100-3-3:2013, AS/NZS CISPR 22:2009 + A1:2010, VCCI V-3/2015.04, V-4/2012.4
Product color	Black, White
Rack mounting	No
Number of multicast groups filtered	128
USB 2.0 ports quantity	2
Installed SFP modules quantity	0
Basic switching RJ-45 Ethernet ports type	Gigabit Ethernet (10/100/1000)
Basic switching RJ-45 Ethernet ports quantity	8
AC input voltage	100 - 240 V
AC input frequency	50 - 60 Hz
Power consumption (max)	26.3 W
Power consumption (typical)	3.3 W
Number of VLANs	64
Networking standards	IEEE 802.1Q, IEEE 802.1p
Virtual LAN features	Port-based VLAN
DHCP features	DHCP client
Jumbo frames	9000
Forwarding rate	11.9 Mpps
Number of queues	4
MAC address table	4000 entries
Heat dissipation	89.8 BTU/h
Operating altitude	0 - 3000 m
Storage temperature (T-T)	-20 - 70 °C
Operating temperature (T-T)	0 - 40 °C
Storage relative humidity (H-H)	0 - 95 %
Operating relative humidity (H-H)	0 - 90 %
Harmonized System (HS) code	85176990

Weight and Dimensions

Depth	164 mm
Width	234 mm
Height	33 mm
Weight	370 g
