NETGEAR GS908E User Manual

The SWITCH DISCOVERY page displays.
6. Enable or disable NSDP by clicking the button in the NSDP section.
When NSDP is enabled, the button displays blue.
7. Click the APPLY button.
Your settings are saved.
Manage Multicast
Multicast IP traffic is traffic that is destined to a host group. Host groups are identified by Class D IP addresses,
which range from 224.0.0.0 to 239.255.255.255. Internet Group Management Protocol (IGMP) snooping
allows the switch to forward multicast traffic intelligently. Based on the IGMP query and report messages,
the switch forwards traffic only to the ports that request the multicast traffic rather than to all ports, which
could affect network performance.
IGMP snooping helps to optimize multicast performance and is especially useful for bandwidth-intensive IP
multicast applications such as online media streaming applications.
Manage IGMP Snooping
Internet Group Management Protocol (IGMP) snooping is enabled by default. Under some circumstances
you might want to temporarily disable IGMP snooping.
To manage IGMP snooping:
1. Open a web browser from a computer that is connected to the same network as the switch or to the
switch directly through an Ethernet cable.
2. Enter the IP address that is assigned to the switch.
The login page displays.
3. Enter the switch password.
The default password is password. The password is case-sensitive.
The HOME page displays.
4. From the menu at the top of the page, select SWITCHING.
The Quality of Service (QoS) page displays.
5. From the menu on the left, select MULTICAST.
The MULTICAST page displays.
6. Enable or disable IGMP snooping by clicking the button in the IGMP Snooping section.
When IGMP snooping is enabled, the button displays blue.
7. Click the APPLY button.
Your settings are saved.
Manage the Switch in Your Network
51
8-Port Gigabit Ethernet Smart Managed Plus Switch Model GS908E

NETGEAR GS908E Specifications

General

Switch type	Managed
Quality of Service (QoS) support	Yes
Safety	IEC 60950-1:2005(ed.2) + A1:2009 + A2:2013, UL 60950-1, CAN/CSA C22.2 No. 60960-1-07, EN 60950-1: 2006 + A11:2009 + A1:2010 + A12:2011 + A2:2013, IEC 60950-1:2005 (ed.2)+A1:2009+A2:2013, AS/NZS 60950.1:2015
Stackable	-
Certification	47 CFR FCC Part 15, ICES-003:2016, ANSI C63.4:2014, EN 55022:2010 + AC:2011, EN 55024:2010, EN 61000-3-2:2014, EN 6100-3-3:2013, AS/NZS CISPR 22:2009 + A1:2010, VCCI V-3/2015.04, V-4/2012.4
Product color	Black, White
Rack mounting	No
Number of multicast groups filtered	128
USB 2.0 ports quantity	2
Installed SFP modules quantity	0
Basic switching RJ-45 Ethernet ports type	Gigabit Ethernet (10/100/1000)
Basic switching RJ-45 Ethernet ports quantity	8
AC input voltage	100 - 240 V
AC input frequency	50 - 60 Hz
Power consumption (max)	26.3 W
Power consumption (typical)	3.3 W
Number of VLANs	64
Networking standards	IEEE 802.1Q, IEEE 802.1p
Virtual LAN features	Port-based VLAN
DHCP features	DHCP client
Jumbo frames	9000
Forwarding rate	11.9 Mpps
Number of queues	4
MAC address table	4000 entries
Heat dissipation	89.8 BTU/h
Operating altitude	0 - 3000 m
Storage temperature (T-T)	-20 - 70 °C
Operating temperature (T-T)	0 - 40 °C
Storage relative humidity (H-H)	0 - 95 %
Operating relative humidity (H-H)	0 - 90 %
Harmonized System (HS) code	85176990

Weight and Dimensions

Depth	164 mm
Width	234 mm
Height	33 mm
Weight	370 g
