NETGEAR GS908E User Manual

VLAN Overview
Virtual LANs (VLANs) are made up of networked devices that are grouped logically into separate networks.
You can group ports on a switch to create a virtual network made up of the devices connected to the ports.
You can group ports in VLANs using either port-based or 802.1Q criteria:
• Port-based VLANs. Assign ports to virtual networks. Ports with the same VLAN ID are placed in the
same VLAN. This feature provides an easy way to partition a network into private subnetworks.
• 802.1Q VLANs. Create virtual networks using the IEEE 802.1Q standard. 802.1Q uses a VLAN tagging
system to determine which VLAN an Ethernet frame belongs to.You can configure ports to be a part
of a VLAN.
When a port receives data that is untagged, the data is delivered normally. However, when a port
receives data that is tagged for a VLAN, the data is discarded unless the port is a member of that VLAN.
This technique is useful for communicating more securely with devices outside your local network as
well as receiving data from other ports that are not in the VLAN.To use an 802.1Q VLAN, you must
know the VLAN ID.
Manage Port-Based VLANs
After you activate the port-based VLAN mode (also referred to as the basic VLAN mode), you can add and
manage port-based VLANs.
Activate the Port-Based VLAN Mode
By default, all types of VLANs are disabled on the switch. Before you can add and manage port-based
VLANs, you must activate the port-based VLAN mode.This mode is also referred to as the basic VLAN
mode.
When you activate the port-based VLAN mode, VLAN 1 is added to the switch and all ports (1 through 8)
are members of VLAN 1. This is the default VLAN in the port-based VLAN mode.
To activate the port-based VLAN mode:
1. Open a web browser from a computer that is connected to the same network as the switch or to the
switch directly through an Ethernet cable.
2. Enter the IP address that is assigned to the switch.
The login page displays.
3. Enter the switch password.
The default password is password. The password is case-sensitive.
The HOME page displays.
4. From the menu at the top of the page, select SWITCHING.
The Quality of Service (QoS) page displays.
5. From the menu on the left, select VLAN.
The VLAN page displays.
Use VLANS for Traffic Segmentation
37
8-Port Gigabit Ethernet Smart Managed Plus Switch Model GS908E

NETGEAR GS908E Specifications

General

Switch type	Managed
Quality of Service (QoS) support	Yes
Safety	IEC 60950-1:2005(ed.2) + A1:2009 + A2:2013, UL 60950-1, CAN/CSA C22.2 No. 60960-1-07, EN 60950-1: 2006 + A11:2009 + A1:2010 + A12:2011 + A2:2013, IEC 60950-1:2005 (ed.2)+A1:2009+A2:2013, AS/NZS 60950.1:2015
Stackable	-
Certification	47 CFR FCC Part 15, ICES-003:2016, ANSI C63.4:2014, EN 55022:2010 + AC:2011, EN 55024:2010, EN 61000-3-2:2014, EN 6100-3-3:2013, AS/NZS CISPR 22:2009 + A1:2010, VCCI V-3/2015.04, V-4/2012.4
Product color	Black, White
Rack mounting	No
Number of multicast groups filtered	128
USB 2.0 ports quantity	2
Installed SFP modules quantity	0
Basic switching RJ-45 Ethernet ports type	Gigabit Ethernet (10/100/1000)
Basic switching RJ-45 Ethernet ports quantity	8
AC input voltage	100 - 240 V
AC input frequency	50 - 60 Hz
Power consumption (max)	26.3 W
Power consumption (typical)	3.3 W
Number of VLANs	64
Networking standards	IEEE 802.1Q, IEEE 802.1p
Virtual LAN features	Port-based VLAN
DHCP features	DHCP client
Jumbo frames	9000
Forwarding rate	11.9 Mpps
Number of queues	4
MAC address table	4000 entries
Heat dissipation	89.8 BTU/h
Operating altitude	0 - 3000 m
Storage temperature (T-T)	-20 - 70 °C
Operating temperature (T-T)	0 - 40 °C
Storage relative humidity (H-H)	0 - 95 %
Operating relative humidity (H-H)	0 - 90 %
Harmonized System (HS) code	85176990

Weight and Dimensions

Depth	164 mm
Width	234 mm
Height	33 mm
Weight	370 g
