NETGEAR GS908E User Manual

9. To change an existing OUI, do the following:
a. Click the down arrow next to the OUI that you want to change.
b. Click the EDIT button.
c. Change the OUI, description, or both.
d. Click the SAVE button.
Your settings are saved.
10. To delete an OUI that you no longer need, do the following:
a. Click the down arrow next to the OUI that you want to delete.
b. Click the DELETE button.
Your settings are saved and the OUI is deleted.
11. Click the BACK button.
The VLAN page displays.
Deactivate the Port-Based or 802.1Q-Based VLAN Mode
and Delete All VLANs
If you activated the port-based VLAN mode or the 802.1Q-based VLAN mode, you can deactivate either
VLAN mode and delete all VLANs.
To deactivate the port-based VLAN mode or 802.1Q-based VLAN mode and delete all VLANs:
1. Open a web browser from a computer that is connected to the same network as the switch or to the
switch directly through an Ethernet cable.
2. Enter the IP address that is assigned to the switch.
The login page displays.
3. Enter the switch password.
The default password is password. The password is case-sensitive.
The HOME page displays.
4. From the menu at the top of the page, select SWITCHING.
The Quality of Service (QoS) page displays.
5. From the menu on the left, select VLAN.
The VLAN page displays.
6. In the No VLANs section, click the ACTIVATE button.
A pop-up window opens, informing you that the current VLAN settings will be lost.
7. Click the CONTINUE button.
Your settings are saved and the pop-up window closes.
Use VLANS for Traffic Segmentation
47
8-Port Gigabit Ethernet Smart Managed Plus Switch Model GS908E

NETGEAR GS908E Specifications

General

Switch type	Managed
Quality of Service (QoS) support	Yes
Safety	IEC 60950-1:2005(ed.2) + A1:2009 + A2:2013, UL 60950-1, CAN/CSA C22.2 No. 60960-1-07, EN 60950-1: 2006 + A11:2009 + A1:2010 + A12:2011 + A2:2013, IEC 60950-1:2005 (ed.2)+A1:2009+A2:2013, AS/NZS 60950.1:2015
Stackable	-
Certification	47 CFR FCC Part 15, ICES-003:2016, ANSI C63.4:2014, EN 55022:2010 + AC:2011, EN 55024:2010, EN 61000-3-2:2014, EN 6100-3-3:2013, AS/NZS CISPR 22:2009 + A1:2010, VCCI V-3/2015.04, V-4/2012.4
Product color	Black, White
Rack mounting	No
Number of multicast groups filtered	128
USB 2.0 ports quantity	2
Installed SFP modules quantity	0
Basic switching RJ-45 Ethernet ports type	Gigabit Ethernet (10/100/1000)
Basic switching RJ-45 Ethernet ports quantity	8
AC input voltage	100 - 240 V
AC input frequency	50 - 60 Hz
Power consumption (max)	26.3 W
Power consumption (typical)	3.3 W
Number of VLANs	64
Networking standards	IEEE 802.1Q, IEEE 802.1p
Virtual LAN features	Port-based VLAN
DHCP features	DHCP client
Jumbo frames	9000
Forwarding rate	11.9 Mpps
Number of queues	4
MAC address table	4000 entries
Heat dissipation	89.8 BTU/h
Operating altitude	0 - 3000 m
Storage temperature (T-T)	-20 - 70 °C
Operating temperature (T-T)	0 - 40 °C
Storage relative humidity (H-H)	0 - 95 %
Operating relative humidity (H-H)	0 - 90 %
Harmonized System (HS) code	85176990

Weight and Dimensions

Depth	164 mm
Width	234 mm
Height	33 mm
Weight	370 g
