• Manually Set Up an ADSL Internet Connection on page 36
• Manually Set Up a VDSL Internet Connection on page 43
• Manually Set Up a Cable or Fiber Internet Connection on page 48
If your ISP provides directions for how to set up VLANs for IPTV and Internet service,
follow those directions.
Note
To enable and configure a VLAN for the virtual Internet interface and another VLAN for the
virtual IPTV interface:
1. Launch a web browser from a computer or WiFi device that is connected to the network.
2. Enter http://www.routerlogin.net.
A login window opens.
3. Enter the modem router user name and password.
The user name is admin.The default password is password. The user name and password are
case-sensitive.
The BASIC Home page displays.
4. Select Internet.
The Internet Setup page displays.
5. Configure a VLAN for the virtual Internet interface:
a. Make sure that Internet is selected from the menu above the Enable This Interface check box and
that the Enable This Interface check box is selected for the virtual Internet interface (it is by default).
b. Select the Use VLANID check box.
c. Enter a VLAN ID that applies to the virtual Internet interface.
The VLAN ID can be in a range from 0 to 4094.The default VLAN ID is 10.
d. To specify a priority for the VLAN, in the Priority (0 ~ 7) field, enter a value from 0 to 7.
e. Click the Apply button.
Your settings are saved for the virtual Internet interface.
6. From the menu above the Enable This Interface check box, select IPTV.
The page adjusts.
7. Configure a VLAN for the virtual IPTV interface:
a. Make sure that the Enable This Interface check box is selected for the virtual IPTV interface.
If you already enabled and configured the virtual IPTV interface, the check box is selected.
b. Select the Use VLANID check box.
c. Enter a VLAN ID that applies to the virtual IPTV interface.
The VLAN ID can be in a range from 0 to 4094.The default VLAN ID is 0.
Manage the WAN and LAN Network Settings
141
Nighthawk AC1900 WiFi VDSL/ADSL Modem Router Model D7000v2
