8. In the IPv6 Address/Prefix Length fields, specify the static IPv6 address and prefix length of the modem
router’s LAN interface.
If you do not specify an address here, the modem router generates one automatically from its MAC
address.
9. Select the IPv6 filtering mode:
• Secured. In secured mode, which is the default mode, the modem router inspects both TCP and
UDP packets.
• Open. In open mode, the modem router inspects UDP packets only.
10. Click the Apply button.
Your settings are saved.
Set Up an IPv6 Pass-Through Connection
In IPv6 pass-through mode, the modem router works as a Layer 2 Ethernet switch with two ports (LAN and
WAN Ethernet ports) for IPv6 packets.The modem router does not process any IPv6 header packets.
Follow the directions that your IPv6 ISP gave you.Note
To set up an IPv6 pass-through Internet connection:
1. Launch a web browser from a computer or WiFi device that is connected to the network.
2. Enter http://www.routerlogin.net.
A login window opens.
3. Enter the modem router user name and password.
The user name is admin.The default password is password. The user name and password are
case-sensitive.
The BASIC Home page displays.
4. Select ADVANCED > Advanced Setup > IPv6.
The IPv6 page displays.
5. From the Internet Connection Type menu, select Pass Through.
The page adjusts, but no additional fields display.
6. Click the Apply button.
Your settings are saved.
Set Up an IPv6 Fixed Connection
A fixed IPv6 connection is based on a static or fixed IPv6 address that your IPv6 ISP gave you.
Follow the directions that your IPv6 ISP gave you.Note
Manage the Internet Settings Manually
61
Nighthawk AC1900 WiFi VDSL/ADSL Modem Router Model D7000v2
