View Devices Currently on the Network
You can view the active wired and WiFi devices in both the network to which the modem router is connected
and the modem router network. If you do not recognize a WiFi device, it might be an intruder.
To display the wired and WiFi devices:
1. Launch a web browser from a WiFi-enabled computer or mobile device that is connected to the network.
2. Enter http://www.routerlogin.net.
A login window opens.
3. Enter the modem router user name and password.
The user name is admin.The default password is password. The user name and password are
case-sensitive.
The BASIC Home page displays.
4. Select Attached Devices.
The Attached Devices page displays.
Wired devices are connected to the modem router with Ethernet cables.WiFi devices are connected to
the modem router through the WiFi network, in either the 2.4 GHz band or the 5 GHz band.
The following table describes the fields on the Attached Devices page.
DescriptionField
For a WiFi device, the WiFi network name (SSID) that the device is using.SSID
If access control is enabled, the access control status of the device in the network (Allowed or
Blocked).
Status
The IP address that the modem router assigned to the device when it joined the network.This
address can change when a device is disconnected and rejoins the network.
IP Address
The unique MAC address.The MAC address does not change and is usually shown on the
product label.
MAC Address
The device name, if detected.Device Name
5. To refresh the information onscreen, click the Refresh button.
The information onscreen is updated.
Manage the Activity Log and Syslog
The log is a detailed record of the websites users on your network accessed or attempted to access and
many other modem router actions. Up to 256 entries are stored in the log.You can manage which activities
are logged.
Manage the Modem Router and Monitor the Traffic
170
Nighthawk AC1900 WiFi VDSL/ADSL Modem Router Model D7000v2
