56 | Chapter 4. Management
ProSafe Wireless-N Access Point WNAP320 Reference Manual
SNMP Management
To set up an SNMP management interface:
1. Select Ma
intenance > Remote Management > SNMP. The SNMP screen displays:
Figure 29.
2. Specify the settings as explained in the following table:
3. Click Apply to save
your settings.
Table 15. SNMP Settings
Field Description
SNMP Select the Enable radio button to allow the SNMP network management
software, such as HP OpenView, to manage the wireless access point
through SNMPv1/v2 protocol. By default, the Disable radio button is
selected.
Read-Only Community Name Enter the community string to allow the SNMP manager to read the
w
ireless access point’s Management Information Base (MIB) objects. The
default is public.
Read-Write Community Name Enter the community string to allow the SNMP manager to read and write
the wir
eless access point’s MIB objects. The default is private.
Trap Community Name The community string to allow the SNMP manager to send traps. The
default is
trap.
IP Address to Receive Traps The IP address of the SNMP manager
to receive traps sent from the
wireless access point.
Trap Port The port number of the SNMP manager to receive traps sent from the
w
ireless access point. The default is 162.
