NETGEAR ProSafe XS728T User Manual

Monitor the System
312
ProSAFE 10-Gigabit Smart Managed Switch XS728T and XS748T User Manual
6. From the Interface menu, select the interface for which you want to view the statistics.
7. From the MST ID menu, select the MST ID associated with the interface (if available).
8. To view more fields, move the gray bar on the right of the page to the bottom of the page.
The following table describes the detailed port information displayed on the page.
Table 66. Detailed port statistics
Field Description
ifIndex This object indicates the ifIndex of the interface table entry associated with this
port on an adapter.
Port Type For normal ports this field displays Normal. Otherwise, the possible values are
as follows:
• Mirrored. The port is participating in port mirroring as a mirrored port. For
more information, see Configure Port Mirroring on page 326.
• Probe. The port is participating in port mirroring as the probe port. For more
information, see Configure Port Mirroring on page 326.
• Port channel. The port is a member of a link aggregation trunk. For more
information, see Configure Link Aggregation Groups on page 88.

NETGEAR ProSafe XS728T Specifications

General

Model	XS728T
Category	Switch
Switching Capacity	560 Gbps
Forwarding Rate	417 Mpps
Ports	24 x 10G SFP+, 4 x 10G Base-T
Management	Web-based, SNMP
Features	ACLs, QoS
Power Supply	Internal 100-240VAC, 50-60Hz
Operating Temperature	0°C to 50°C (32°F to 122°F)
Operating Humidity	90% maximum relative humidity, non-condensing
MAC Address Table Size	32, 000 entries
