User Manual HX4E/MX8A Series Voice Gateway
28 www.newrocktech.com
Figure 2-14 MGCP Configuration Interface
Table 2-9 MGCP Configuration Parameters
Configure the UDP port for transmitting and receiving MGCP messages, and
the default value is 2427.
Note: The signaling port number can be set in the range of 1-9999, but cannot
conflict with the other port numbers used by the equipment.
Configure the IP address and port number of MGCP proxy server, separated by
“:”. It has no default value.
The address can be set to an IP address or a domain name according to the
subscribers’ requirements. When a domain name is used, it is required to
configure DNS server on the "Basic > Network" page. Examples of complete
and effective configuration: 46.33.136.50:2727 or www.proxy.com: 2727.
The domain name associated with the call agent, and it has no default value.
DNS server is required to set.
Example: www.gatewaymgcp.com.
List all the types of default event packages supported by the HX4. Multiple
package names are separated by“,”.
The default value is L, D, G
L: Line Package
D: DTMF Package
G: Generic Media Package
List the event types that the gateway can report, with multiple types separated
by “,”. When gateways process the events listed here, they will report to the call
agent.
Note: This parameter must be set since there is no default value. The factory
setting is L/HD, L/HU:
L/HD: Offhook
L/HU: Onhook
